ASSEMBLY INSTRUCTIONS FOR THE EFOILSOLUTIONS WAYDOO / AXIS ADAPTER These instructions apply to both Black and Red Series Axis Adapters Temporarily connect the wing to the adapter, using the four bolts provided. Note: The four bolts are longer than the standard Axis bolts. Verify that the bolts fully engage with the aluminum plate but do not protrude past the plate. Unscrew and remove the wing from the adapter. Connect the adapter to the Waydoo Efoil with the two M6 x 20mm bolts provided. Re-connect the Axis wing to the Adapter. Shimming: Add -1, -2, or both (-3) between the plate and efoil to decrease the nose-up pressure (to point the board nose down). Use the “+” shims to increase nose pressure. ...
ASSEMBLY INSTRUCTIONS FOR THE EFOILSOLUTIONS FLITEBOARD / SABFOIL ADAPTER Optional: If using M8 bolts to connect to the Sabfoil wing (not provided), remove M6 to M8 threaded inserts. Connect the adapter to the Fliteboard Efoil with the back two M6 x 20mm bolts provided. Connect the Sabfoil wing to the Adapter using the provided bolt set. Bolts for this connection are longer than the standard Sabfoil bolt set. The back bolt should not protrude above the adapter metal plate. The middle bolt extends from the wing, through the adapter and to the Fliteboard front threaded M6 hole. Shimming: Add -1, -2, or both (-3) to decrease the nose-up pressure (to point the board nose down). Use the “+” shims to...
ASSEMBLY INSTRUCTIONS FOR THE EFOILSOLUTIONS WAYDOO / SABFOIL ADAPTER Optional: If using M8 bolts to connect to the Sabfoil wing (not provided), remove three M6 to M8 threaded inserts. Connect the adapter to the Waydoo Efoil with the two M6 x 20mm bolts provided. Connect the Sabfoil wing to the Adapter. Note: Bolts for this connection are longer than the standard bolt set. The back and middle bolts should not protrude above the metal plate. Shimming: Add -1, -2, or both (-3) between the plate and efoil to decrease the nose-up pressure (to point the board nose down). Use the “+” shims to increase nose pressure. NOTE THAT SHIMMING MAY REQUIRE LONGER BOLT(S). Spacer ShimSome Waydoo connection plates may have...
ASSEMBLY INSTRUCTIONS FOR THE EFOILSOLUTIONS FLITEBOARD / AXIS ADAPTER These instructions apply to both Black and Red Series Axis Adapters Temporarily connect the wing to the adapter, using the four bolts provided. Note: The four bolts are longer than the standard Axis bolts. Verify that the bolts fully engage with the aluminum plate but do not protrude past the plate. Unscrew and remove the wing from the adapter. Connect the adapter to the Fliteboard Efoil with the three M6 x 20mm bolts provided. Re-connect the Axis wing to the Adapter. Shimming: Add -1, -2, or both (-3) between the plate and efoil to decrease the nose-up pressure (to point the board nose down). Use the “+” shims to increase nose pressure. ...
